ADC Interrupt Trigger SOC Select
Registers 1 & 2
AdcRegs.ADCINTSOCSELx
15 - 14
SOC15 SOC14 SOC13 SOC12 SOC11 SOC10 SOC9 SOC8
13 - 12 11 - 10 9 - 8 7 - 6 5 - 4 3 - 2 1 - 0
15 - 14
SOC7 SOC6 SOC5 SOC4 SOC3 SOC2 SOC1 SOC0
13 - 12 11 - 10 9 - 8 7 - 6 5 - 4 3 - 2 1 - 0
ADCINTSOCSEL2
ADCINTSOCSEL1
SOCx ADC Interrupt Select
Selects which, if any, ADCINT triggers SOCx
00 = no ADCINT will trigger SOCx (TRIGSEL field determines SOCx trigger)
01 = ADCINT1 will trigger SOCx (TRIGSEL field ignored)
10 = ADCINT2 will trigger SOCx (TRIGSEL field ignored)
11 = invalid selection
ADC Sample Mode Register
AdcRegs.ADCSAMPLEMODE
reserved
15 - 8
7
SIMULEN14 SIMULEN12 SIMULEN10 SIMULEN8 SIMULEN6 SIMULEN4 SIMULEN2 SIMULEN0
6 5 4 3 2 1 0
Simultaneous Sampling Enable
Couples SOCx and SOCx+1 in simultaneous sampling mode
0 = single sample mode for SOCx and SOCx+1
1 = simultaneous sample mode for SOCx and SOCx+1
