Thermo King SR-2 SmartReefer2 - H04 A: Wiring Harness Continuity Test

Section 6 – SR-2 Service Procedure H04A
Wiring Harness Continuity Test
Where Used
All SR-2 units
Purpose
To illustrate the correct procedures for checking harness continuity on equipment utilizing solid state devices
Table of Contents
Wiring Harness Continuity Test................................................................................................................................. 1
Where Used ........................................................................................................................................................... 1
Purpose.................................................................................................................................................................. 1
Table of Contents................................................................................................................................................... 1
Materials Required................................................................................................................................................. 1
Important Notes...................................................................................................................................................... 1
Diagnostic Procedure............................................................................................................................................. 2
Materials Required
• Fluke Digital Multimeter.
• Jumper Wires as Required
Important Notes
• Do not use battery and light test tools to check continuity.
• Do not check to see if a circuit is energized by tapping a circuit wire to ground and watching for a spark
.
Page 1
P41RH04A 30 January 2005
