Acquiring Sample Data
Using Tune to Acquire Sample Data
Thermo Scientific TSQ Altis, Quantis, and Fortis Hardware Manual 83
Figure 42. Data Acquisition pane in the Tune window
4. Click Record to start data acquisition.
After the Tune parameters reach their specified settings, the data acquisition process
begins and the small circle on the Record button turns red ( ).
5. When you are ready, click Record again to stop the acquisition.
The small circle on the Record button turns gray (not recording).
For more information about reviewing the acquired data, refer to the Thermo FreeStyle or the
FreeStyle Help.
No. Description
1. Click to open/close the Data Acquisition pane
2. File name box
3. Start/stop/pause the data acquisition recording.
1
2
3
