Using Basic Tune Functions
Setting the Instrument Power Mode
116 TSQ Altis, Quantis, and Fortis Hardware Manual Thermo Scientific
Setting the Instrument Power Mode
Use the three power mode icons in the Tune window (Figure 59) to set the MS’s power mode
(on, standby, or off ).
When you remove the API source housing or the spray insert, the MS automatically switches
to off mode.
In standby mode, the System LED on the front panel turns yellow and the MS turns off the
electron multipliers, conversion dynodes, 8 kV power to the API source, main RF voltage,
and ion optic RF voltages. The auxiliary, sheath, and sweep gas flows remain on and return to
their standby default settings (2 arbitrary). See Chapter 8, “Using the MS Power Options.”
Divert/inject valve
To set the divert/inject valve module and position
Click the down arrow to select the valve, and then
click Valve to set the position.
Syringe pump
To turn the syringe pump on or off
Click Syringe On (Off) to switch between on and
off.
To set the syringe pump parameters
1. Click the down arrow, and then type the values.
The Tune application automatically saves the values.
2. (Optional) Press and hold Prime to prime the syringe
at 100 μL/min.
3. Click the down arrow again or click elsewhere to
close the box.
Table 17. Procedures for using the instrument control buttons (Sheet 2 of 2)
Button Function Procedure
