Connecting the Sample Flow to the Source

Connecting the Sample Flow to the APCI Source

Thermo Scientific TSQ Altis, Quantis, and Fortis Hardware Manual 53

Figure 24. Connection to the APCI spray insert

No. Description

1. Tubing from sample flow (red PEEK or natural PEEK (nano-Viper))
