E
Replaceable Parts
Single Mechanical Pump Kit
144 TSQ Altis, Quantis, and Fortis Hardware Manual Thermo Scientific
Single Mechanical Pump Kit
Single Mechanical Pump Kit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80100-62004
Forepump, Oerlikon Leybold Vacuum™, SOGEVAC™ SV 65 BI,
single-phase 230 Vac, 50/60 Hz . . . . . . . . . . . . . . . . . . . . . . . . . . 00108-01-00032
Forepump oil tray, stainless steel, caster wheels . . . . . . . . . . . . . . . . . .00201-99-00549
Accessories Single Mechanical Pump Kit (Tab le 21) . . . . . . . . . . . . . . . . . 80100-62015
Dual Mechanical Pumps Kit
Dual Mechanical Pumps Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80100-62013
Forepump, Oerlikon Leybold Vacuum, SOGEVAC SV 65 BI,
single-phase 230 Vac, 50/60 Hz (2 provided). . . . . . . . . . . . . . . . 00108-01-00032
Forepump oil tray, stainless steel, caster wheels (2 provided) . . . . . . . . .00201-99-00549
Accessories Dual Mechanical Pump Kit (Ta bl e 2 3) . . . . . . . . . . . . . . . . . . 80100-62016
Table 21. Accessories Single Mechanical Pump Kit (P/N 80100-62015)
Item Part number
90-Degree Elbow Installation Kit (2 provided, Tab le 22) 97055-62036S
Relay control cable, single pump, 2.4 m (8 ft) long (preassembled) 80000-63139
Single pump vacuum hose assembly, KF40, 2.4 m (8 ft) long
(preassembled)
80000-60229
Tubing, Tygon, 3/4 in. (19.1 mm) OD, 0.5 in. (12.7 mm) ID, 3 m
(10 ft) long
00301-22920
Table 22. 90-Degree Elbow Installation Kit (P/N 97055-62036S)
Item Part number
Centering ring with O-ring, nitrile and aluminum, NW40 00108-02-00005
Elbow, aluminum, NW40, 90 degree 00108-02-00010
Swing clamp, aluminum, NW32/40 00108-02-00004
Table 23. Accessories Dual Mechanical Pump Kit (P/N 80100-62016)
Item Part number
90-Degree Elbow Installation Kit (3 provided, Tab le 22) 97055-62036S
Dual relay control cable, 2.4 m (8 ft) long (preassembled) 80100-63146
Dual pump vacuum hose assembly (preassembled) 80100-60049
Fitting Tee, barbed, nylon, for 0.5 in. (12.7 mm) ID tubing 00103-01-00012
Tubing, Tygon, 3/4 in. (19.1 mm) OD, 0.5 in. (12.7 mm) ID, 6 m
(20 ft) long
00301-22920
