Maintaining the API Source Interface

Cleaning the Ion Sweep Cone

Thermo Scientific TSQ Altis, Quantis, and Fortis Hardware Manual 109

7. Dry the component thoroughly with nitrogen gas.

8. Using a magnification device, inspect the component for any residual lint or particulates.

9. After you clean and reinstall these components, turn on the nonvacuum system voltages

by placing the MS's electronics service switch in the Operating Mode (up) position.

To determine if you have successfully unblocked the ion transfer tube, check that the

Source Pressure reading has increased to a normal value.

10. If the ion transfer tube is still blocked, replace it.

Table 16. Vacuum specification with ion transfer tube installed and open

Region TSQ Altis TSQ Quantis TSQ Fortis

Source Pressure less than 3.8 Torr less than 2.0 Torr less than 2.0 Torr
