Mechanical Dimensions
L
Max.
17.1
Module length
W
Max.
19.1
Module width
H
Max.
14.6
Module height (option without supercapacitor)
I
Min.
2.5
Lead length
p
Aver.
1.27
Pin pitch
Dimensions are for reference only. Tibbo assumes no responsibility for any errors in
this Manual, and does not make any commitment to update the information
contained herein.
Ordering Info and Specifications
Device numbering scheme is as follows:
512K devices are no longer available.
If the flash memory size is omitted, 1024K option is implied.

Tibbo DS1100 Specifications

General

Brand	Tibbo
Model	DS1100
Category	Controller
Language	English
