479 Programmable Hardware Manual (PHM)
© Tibbo Technology Inc.
·
Platform objects:
- Sock — socket communications (up to 16 UDP, TCP, and HTTP sessions);
- Net — controls the Ethernet port;
- Wln — handles the Wi-Fi interface (requires GA1000 add-on module);
- Ser — in charge of serial channels;
- Ssi — implements up to four serial synchronous interface (SSI) channels,
supports SPI, I2C, clock/data, etc.;
- Io — handles I/O lines, ports, and interrupts;
- Rtc — keeps track of date and time;
- Fd — manages flash memory file system and direct sector access;
- Stor — provides access to the EEPROM;
- Romfile — facilitates access to resource files (fixed data);
- Pppoe — provides access to the Internet over an ADSL modem;
- Ppp — provides access to the Internet over a serial modem (GPRS, POTS, etc.);
- Pat — "plays" patterns on green and red status LEDs;
- Beep — generates buzzer patterns;
- Button — monitors the setup button;
- Sys — in charge of general device functionality.
Common Features of the DS10xx Family
This section describes all common features of the DS10xx family:
·
Secondary cover
·
DIN rail mounting
8.4.1.1
Secondary Cover
All DS10xx devices are dust- and water-proof to IP68 when used with the properly
installed secondary cover. Diagram below shows the procedure of waterproofing any
DS10xx device. Shown on the diagram are devices with terminal blocks (DS1004,
DS1005). Other devices in the DS10xx series have DB9 connectors (see DS1000,
DS1002, DS1003). Tibbo offers a TB1000 terminal block adaptor that "converts" DB9
connector into terminal blocks. The TB1000 is compatible with the secondary cover.
