Tibbo DS1100 User Manual

326Tibbo Project System (TPS)
© Tibbo Technology Inc.
up to 1A
@ 12V
up to 70C
up to 1.5A
@ 24V
up to 60C
up to 1.0A
@ 24V
up to 80C
up to 1.0A
@ 48V
up to 60C
up to 1.0A
@ 60V
up to 50C
up to 0.5A
@ 48V
up to 80C
up to 0.5A
@ 60V
up to 70C
Multiple power supply Tibbits can be used to increase available current or for power
redundancy.
The module has a dedicated shutdown (-SDWN) line. Pull the line LOW to disable
this Tibbit.
Combine this Tibbit with #18 (it has a power jack and two terminal blocks), #20
(nine terminal blocks), or #21 (four terminal blocks).
LEDs
There is one green and one red LED. The green LED is connected to the +5V output
and lights up when the voltage is present on this line. Red LED is connected to the -
SHUTDOWN line and lights up when the line is LOW (i.e. when the power supply is in
shutdown).
7.2.9.36
#26, M1S: IR Command Processor
Function: Records and plays back infrared commands (codes) of conventional IR
remote controls
Form factor: M1S
Category: Input/output module
Special needs: ---
Power requirements: 5V/100mA
Mates with: #19, #20, #21
See also: ---
