Interface signals
The clock frequency is supplied via the MCLK (master clock) line. BCLK and WCLK
clocks are generated by the audio IC and are fed back into the sound port on the
LTPP board's processor. The audio data is transmitted via DIN and DOUT lines. There
is also an additional I2C port (SCL and SDA lines) that is used for configuring the
codec.
LEDs
There are three green, four red, and one yellow LED. Green LEDs are connected to
BCLK, WCLK, and DOUT lines. Red LEDs are connected to MCLK, RESET, I2C_SCL,
and DIN lines. The yellow LED is connected to the I2C_SDA line.
7.2.9.55
#49, C2: Micro SD Card Slot [DEPRECATED]
THIS TIBBIT HAS BEEN DEPRECATED
Function: Micro SD Card Slot
Form factor: C2
Special needs: [MMC]
Power requirements: 5V/10mA
See also: ---
Mates with: #00-1 (two #00-1s are required)
