Details
This C1 device requires the Tibbit #00-3 to be installed in the neighboring "M" Tibbit
socket.
The output signal will be available on line A of Tibbit #00-3. The output will be LOW
when the button is pressed.
7.2.9.46
#39-1~4, C1: Large LED (Four Colors Available)
Function: Large LED (red, blue, green, and yellow colors available)
Form factor: C1
Special needs: Tibbit #00-3
Power requirements: 5V/30mA
See also: #38
