Tibbo DS1100 User Manual

161 Programmable Hardware Manual (PHM)
© Tibbo Technology Inc.
IB1002
The IB1002 board and LB1001 LED board mounted on
the IB1002 and connected to the latter with the
LC1000 cable. Also included is the TB1000 terminal
block adaptor.
IB1003
The IB1002 board and LB1001 LED board mounted on
the IB1002 and connected to the latter with the
LC1000 cable. Also included is the TB1000 terminal
block adaptor.
Hardware specifications
Serial port lines
RS232 mode: RX, TX, CTS, RTS, DSR, DTR
RS422 mode (IB1002/3): RX+/-, TX+/-, CTS+/-,
RTS+/-
RS485 mode (IB1002/3): RX+/-, TX+/-
Baudrate
Up to 460800bps
Operating temperature
-30 to +80 degrees C
Operating relative humidity
10-90%
Board dimensions
76x85mm
All specifications are subject to change without notice and are for reference only.
Tibbo assumes no responsibility for any errors in this Manual, and does not make
any commitment to update the information contained herein.
Think the above table should contain additional data? Do not just assume that you
know the answer — talk to Tibbo! Remember that the ultimate responsibility for all
decisions you make regarding the use and the mode of use of Tibbo products lies
with you, our Customer.
5.3.2.2
IB1004 and SB1004 (Analog I/O)
Featuring 8 analog inputs and 4 analog outputs, the IB1004 + SB1004 board
combination is ideally suited for industrial (building) control and data acquisition
applications. Additional relays and the RS232/485 serial port further expand product
capabilities. To improve reliability and conversion precision, the A/D and D/A portions
each have their own power/ground domains that are fully isolated from the rest of
the circuitry.
