This Tibbit was designed for use with the LTPP3 board, which has now been
superseded by the LTPP3(G2) board.
The Tibbit is not compatible with the LTPP3(G2).
Details
This Tibbit features an isolated power supply that can provide up to 200mA of
power to attached CAN devices.
This Tibbit is only supported on Linux-based boards, such as the LTPP3 board.
LEDs
There are two LEDs: one red and one green connected to the TX and RX lines
correspondingly.
7.2.9.58
#52, M2S: Four-channel Isolated +/-10V ADC
Function: Four-channel isolated +/-10V ADC
Form factor: M2T
Category: Input module
Special needs: --- (isolated power is generated internally)
Power requirements: 5V/100mA
Mates with: #19, #20
See also: #13, #31
