Optional Wi-Fi Interface
The TPP2 can optionally accommodate the WA2000 Wi-Fi add-on module.
The following GPIO lines are used to control the WA2000:
GPIO line
Function
WA2000 pin
49
CS
3
50
DO
(1)
5
51
RST
7
52
DI
(2)
9
53
CLK
10
Notes:
1. "Data out" line of the TPP2, connects to the "data in" on the WA2000.
2. "Data in" line of the TPP2, connects to the "data out" on the WA2000.
Wi-Fi data communications is the responsibility of the sock. object (see TIDE, TiOS,
Tibbo BASIC, and Tibbo C Manual). Before such data communications can take
place, the Wi-Fi interface must be properly configured. This is jointly achieved by
the wln. object and WLN library (again, see TIDE, TiOS, Tibbo BASIC, and Tibbo C
Manual).
