352Tibbo Project System (TPS)
© Tibbo Technology Inc.
#6
Isolated DSR (input)
Isolated RX+ (input)
Isolated RX+ (input)
#7
Isolated RTS
(output)
Isolated RTS+
(output)
<No connection>
#8
Isolated CTS (input)
Isolated CTS+
(input)
<No connection>
#9
<No connection>
Isolated CTS- (input)
<No connection>
The above pin assignment is standard for all Tibbo devices with the universal port
(for example, see the serial port of the DS1102).
LEDs
There are eight LEDs: five red and three green. Red LEDs are connected to TX, RTS,
DTR, FD/-HD, and -232/422-485 lines. Green LEDs are for RX, CTS, and DSR.
All LEDs are buffered (with logic gates) and light up for the LOW state of
corresponding control lines.
7.2.9.51
#44-2, H2: Isolated RS232/422/485 Port (Terminal Block)
Function: Universal galvanically isolated RS232/422/485 port with a terminal block
connector
Form factor: H2
Category: Input/output module
Special needs: [SER], [INT].
Power requirements: maximum 5V/80mA
Mates with: ---
See also: #44-1, #01, #02, #05
