194Boards
© Tibbo Technology Inc.
LB100x mounting hole dimension
LB100x mounting hole, copper area diameter
Dimensions are for reference only. Tibbo assumes no responsibility for any errors in
this Manual, and does not make any commitment to update the information
contained herein.
5.3.5.2
SB100x Board Dimensions
The supplementary board ("SB") has the same height as the interface board ("IB").
The "SB" is narrower -- its maximum width is limited to 67mm. The limit is due to the
interboard connector protruding from the side of the "IB". The "SB" does not have to
have the maximum width -- it can be as short as permitted by the design.
