Tibbo DS1100 User Manual

113 Programmable Hardware Manual (PHM)
© Tibbo Technology Inc.
44
(1,2)
GPIO36/P4.4
General-purpose I/O line 36 (P4.4).
45
(1,2)
GPIO39/P4.7
General-purpose I/O line 39 (P4.7).
46
(1,2)
GPIO38/P4.6
General-purpose I/O line 38 (P4.6).
47
MD
Mode selection pin.
48
(1,2)
GPIO55
General-purpose I/O line 55 (does not
belong to any 8-bit port).
49
RST
Reset line, active high.
50
(1,2)
GPIO54
General-purpose I/O line 54 (does not
belong to any 8-bit port).
51
SR
Red status LED control line.
52
SG
Green status LED control line.
53
(1,2)
GPIO46
General-purpose I/O line 46.
54
(1,2)
GPIO45/CO
General-purpose I/O line 45 (does not
belong to any 8-bit port);
square wave output line.
55
(1,2)
GPIO48
General-purpose I/O line 48 (does not
belong to any 8-bit port).
56
(1,2)
GPIO47
General-purpose I/O line 47 (does not
belong to any 8-bit port).
57
DBGRX
RX line of debug serial port.
58
3.3V
Direct 3.3V power input or 3.3V power
output if you are supplying 12V power via a
power jack or VIN pin.
59
DBGTX
TX line of debug serial port.
60
VIN (12V NOM.)
12V (nominal) power input to the onboard
power regulator. Acceptable input voltage
range is 8-20V.
61
GND
Wireless add-on port, ground line.
62
VCC
Wireless add-on port, 3.3V power output for
the wireless add-on module.
63
(1,2)
GPIO49
Wireless add-on port, general-purpose I/O
line 49 (does not belong to any 8-bit port).
64
<N.C.>
Leave this pin unconnected.
65
(1,2)
GPIO50
Wireless add-on port, general-purpose I/O
line 50 (does not belong to any 8-bit port).
66
<N.C.>
Leave this pin unconnected.
67
(1,2)
GPIO51
Wireless add-on port, general-purpose I/O
line 51 (does not belong to any 8-bit port).
68
<N.C.>
Leave this pin unconnected.
69
(1,2)
GPIO52
Wireless add-on port, general-purpose I/O
line 52 (does not belong to any 8-bit port).
70
(1,2)
GPIO53
Wireless add-on port, general-purpose I/O
line 53 (does not belong to any 8-bit port).
