Tibbo DS1100 User Manual

126Boards
© Tibbo Technology Inc.
Switching regulator supply
voltage (supplied via the
power jack or VIN pin)
unregulated, 8-20V input range, 12V nominal
Direct system power
(supplied via the 3.3V pin
bypassing the switching
regulator)
regulated, 3.3V +/- 10%
Available current on the 3.3V
pin (when powering through
the voltage regulator)
1.0A if the WA2000 is used
1.3A if the WA2000 is not used
Reset circuit trip voltage
(3.3V system power line)
~2.95V on power-up (i.e. when the voltage on
VCC is rising)
~2.85V on brown-out (i.e. when the voltage on
VCC is dropping)
Operating current when the
3.3V is supplied directly
through the 3.3V pin
100mA at full speed, 100BaseT Ethernet mode
Operating temperature
-40 to +80 degrees C
Operating relative humidity
10-90%
Mechanical dimensions
(excluding RJ45 and power
jack)
EM2001: 75x36x17.5mm
EM2001G: 75x36x19mm
All specifications are subject to change without notice and are for reference only.
Tibbo assumes no responsibility for any errors in this Manual, and does not make
any commitment to update the information contained herein.
Think the above table should contain additional data? Do not just assume that you
know the answer — talk to Tibbo! Remember that the ultimate responsibility for all
decisions you make regarding the use and the mode of use of Tibbo products lies
with you, our Customer.
