208Boards
© Tibbo Technology Inc.
Model number
Description
DS1206N-RS
DS1206N device with 1024KBytes of flash memory, "-
RS" version
DS1206N-TM
DS1206N device with 1024KBytes of flash memory, "-
TM" version
Hardware specifications
Ethernet interface
10/100BaseT Ethernet, Auto-MDIX
Serial ports
One serial port with 3.5 serial channels (four inputs
and three outputs), optional "12V" power output on
pin 9
DS1206N-...-RS: RS232 port on the DB9M
connector
DS1206N-...-TM, DS1206N-...-TS: TTL serial port
on the pin header connector
UART capabilities
Baudrates up to 921'600bps;
none/even/odd/mark/space parity and 7/8
bits/character.
Clock frequency
11.0592MHz with PLL off
88.4736MHz with PLL on
Flash memory
512KBytes or 1024KBytes, entire memory minus
64KB is available to store Tibbo BASIC/C application
and data.
Typical write endurance is 100'000 write cycles per
256-byte sector. See the warning in Flash and
EEPROM Memory.
EEPROM memory
2048 bytes, 2020 bytes available to store
application data.
Typical write endurance is around 1'000'000 write
cycles per 16-byte EEPROM sector. See Prolonging
and Estimating EEPROM life.
Supply voltage range
DS1206N-...-RS, DS1206N-...-TM: DC 10-24V (12V
nominal)
DS1206N-...-TS: DC 3.3V (+/- 5%)
Operating temperature
-5 to +70 degrees C
Operating relative humidity
10-90%
Board dimensions
52.6x38.0mm
All specifications are subject to change without notice and are for reference only.
Tibbo assumes no responsibility for any errors in this Manual, and does not make
any commitment to update the information contained herein.
Think the above table should contain additional data? Do not just assume that you
know the answer — talk to Tibbo! Remember that the ultimate responsibility for all
decisions you make regarding the use and the mode of use of Tibbo products lies
with you, our Customer.
