396Tibbo Project System (TPS)
© Tibbo Technology Inc.
·
10/100BaseT auto-MDIX Ethernet port (automatic detection of "straight" and
"cross" cables)
·
Optional Wi-Fi interface (requires the WA2000 add-on module)
·
Optional GPRS interface (requires Tibbit #47)
·
Seven tiles with 47 general-purpose I/O lines
o Fourteen sockets for Tibbit modules
o Fourteen sockets for Tibbit connectors
o One extra socket for Tibbit #37
o Four Tibbit module sockets have UART capability
§
Baudrates of up to 921,600bps
§
None/even/odd/mark/space parity modes
§
7/8 bits/character
§
Full-duplex mode with RTS/CTS and XON/XOFF flow control
§
Half-duplex mode with direction control
§
Encoding and decoding of Wiegand and clock/data streams
o Eight module sockets have an interrupt capability
o One module socket has PoE capability
o Four remappable synchronous serial ports with SPI and I2C modes
·
Onboard buzzer
·
RTC with a backup supercapacitor
·
22KB SRAM for Tibbo BASIC/C variables and data
·
1MB flash memory for TiOS, application code, and file system
·
2048-byte EEPROM for data storage
·
Eight onboard LEDs
o Green and Red main status LEDs
o Yellow Ethernet link LED
o Five blue LEDs (for Wi-Fi signal strength indication, etc.)
·
Software-controlled PLL for selecting high or low speed
·
Reliable power-on/ brown-out reset circuit
·
Power: 220mA @ 3.3V (100Base-T mode, full speed)
·
Dimensions (LxW): 165 x 94mm
·
Operating temperature range: -40°C to 70°C
·
Firmware is upgradeable through the serial port or network
·
Tibbo BASIC/C application can be debugged through the Ethernet LAN
·
CE and FCC-certified
Programming features
·
Platform objects:
o beep — generates buzzer patters
o button — monitors the MD button
o fd — manages the flash memory file system and direct sector access
