446External Controllers
© Tibbo Technology Inc.
"12V" power
input on pin 9 of
DB9
"12V" power input
and output on pin
9 of DB9
(software-
controllable)
512KB for
firmware and
application
storage. No
flash disk
functionality.
1024KB for firmware, application and data
(flash disk)
Red and green
status LEDs
Yellow Ethernet
link LED
Red and green status LEDs
Yellow Ethernet link LED
Five blue LEDs (can be used for Wi-Fi
signal strength indication)
optional 802.11abgn interface (WA2000)
optional 802.11bg interface (GA1000) —
OBSOLETE
optional 96x32 monochrome OLED
Operating
frequency and
PLL
88MHz, software-controlled PLL
Through the
serial port or
network
(including cold
upgrades
through the
network).
Through the serial port or network (no
cold upgrades through the network).
* Wi-Fi and PoE options are mutually exclusive.
Common hardware features of the DS110x family
·
10/100BaseT auto-MDIX Ethernet port.
·
Power: 12VDC nominal (min. 9V, max. 18V).
·
Dimensions: 90x48x25mm.
·
Operating temperature range: -5 ~ 70 C.
·
CE- and FCC-certified.
