Tibbo DS1100 User Manual

493 Programmable Hardware Manual (PHM)
© Tibbo Technology Inc.
Ad
dr.
Name
R/
W
Typ
e
Description
0x
60
0
AXIS_X
_PROC
R
Sign
ed
16-
bit
Processed fixed-point X-axis acceleration data
expressed in steps of ~0.003G.
Measurement resolution is ~0.003 G.
0x
60
1
AXIS_X
_RAW
R
Sign
ed
16-
bit
Raw X-axis acceleration data from the
measurement IC (ADXL312).
See vendor datasheet for details.
0x
60
2
AXIS_Y
_PROC
R
Sign
ed
16-
bit
Processed fixed-point Y-axis acceleration data
expressed in steps of ~0.003G.
Measurement resolution is ~0.003 G.
0x
60
3
AXIS_Y
_RAW
R
Sign
ed
16-
bit
Raw Y-axis acceleration data from the
measurement IC (ADXL312).
See vendor datasheet for details.
0x
60
4
AXIS_Z
_PROC
R
Sign
ed
16-
bit
Processed fixed-point Z-axis acceleration data
expressed in steps of ~0.003G.
Measurement resolution is ~0.003 G.
0x
60
5
AXIS_Z
_RAW
R
Sign
ed
16-
bit
Raw Z-axis acceleration data from the
measurement IC (ADXL312).
See vendor datasheet for details.
