UART capabilities
Baudrates up to 460'800bps;
none/even/odd/mark/space parity and 7/8
bits/character (7 bits/character and "none" parity
cannot be used together).
Number of I/O lines
10 I/O lines: 8 GPIO lines plus TX and RX lines of
the serial port;
GPIO lines are combined into an 8-bit port;
2 GPIO lines can be used as interrupt lines;
I/O lines are NOT 5V-tolerant.
Max. load current for each
I/O line
10mA
Flash memory
512 KBytes, 224KBytes are available to store a
compiled Tibbo BASIC/C application;
this memory cannot be used as a flash disk.
EEPROM memory
2048 bytes, 2016 bytes are available to store
application data.
The typical write endurance is around 1'000'000
write cycles per 8-byte EEPROM sector. See
Prolonging and Estimating EEPROM life.
Nominal power supply
voltage (VCC pin)
DC 3.3V, +/- 5%
Operating current (VCC
pin)
110mA
Operating temperature
-40 to +85 degrees C
Operating relative humidity
10-90%
Mechanical dimensions
(excl. leads)
18.5x16.0x6.5mm
Pin diameter
0.4mm
Packaging
Tray, 30 modules/tray
All specifications are subject to change without notice and are for reference only.
Tibbo assumes no responsibility for any errors in this Manual, and does not make
any commitment to update the information contained herein.
Think the above table should contain additional data? Do not just assume that you
know the answer — talk to Tibbo! Remember that the ultimate responsibility for all
decisions you make regarding the use and the mode of use of Tibbo products lies
with you, our Customer.
