Static routes
USER GUIDE
147
In the same way the command:
set route host 10.1.10.10 dev null0
blocks traffic towards host 10.1.10.10.
The ip command, gives the possibility to specify routes such as: blackhole, prohibit and
unreachable. For example:
ip route add blackhole 1.1.1.1
ip route add prohibit 2.2.2.2
ip route add unreachable 3.3.3.3
Using blackhole parameter, outgoing packets will be rejected, as for null0 route.
Using prohibit parameter, packets will be rejected but a Prohibit ICMP packet will be sent to the IP
source.
Using unreachable parameter, packets will be rejected but an Unreachable ICMP packet will be
sent to the IP source.
DISPLAYING STATIC ROUTES
The static routes configured can be displayed using the following command:
show ip route
For example:
root@IMOLA> show ip route
Router# show ip route
Codes: K - kernel route, C - connected, S - static, R - RIP, O - OSPF,
B - BGP, > - selected route, * - FIB route
C>* 10.10.0.0/16 is directly connected, eth0
B>* 11.11.0.0/16 [20/0] via 172.151.113.100, eth1, 09:39:06
R 11.11.0.0/16 [120/2] via 172.151.113.100, eth1, 09:39:30
C>* 11.11.11.11/32 is directly connected, ippp1
C>* 100.100.100.0/30 is directly connected, tun0
R>* 111.111.111.111/32 [120/2] via 172.151.113.100, eth1, 09:39:30
C>* 127.0.0.0/8 is directly connected, lo
C>* 172.151.0.0/16 is directly connected, eth1
C>* 202.202.202.202/32 is directly connected, dummy0
Router#
root@IMOLA>
In this way the protocol of the routes acquisition is visible.
For IPv6 routes the command is: show ipv6 route.
The command show ip route can have options, the most commonly used are:
show ip route static
show ip route bgp
show ip route ospf
show ip route rip
