ACCESSING IMOLA
Access can be made via the console port with DB9 male connector on the front of Imola, with a
proper null modem cable, using any program of terminal emulation (HyperTerminal, Minicom,
Putty, ...) or via a Telnet connection to one of the IP addresses present on Imola.
Imola LX models have only a 4 ports integrated switch, each numbered 1 to 4. The factory
configuration, all the ports refers to a single IP address on the logical interface eth0.
The other models have a single Fast Ethernet port identified by the label eth0 and a 5 ports
integrated switch (8 in some models), where the ports are numbered 1 to 5 (or 8). In the factory
configuration all the switch ports refers to a single IP address and the logic interface is named eth1.
In case of direct connection to the single Ethernet port of Imola Full model (eth0 port) a LAN cross
cable should be used. Thanks to the auto-mdx function any kind of cable may be used in case of
connection to any port of the integrated switch.
Tiesse spa - IMOLA Interworking Unit
No Radius configured. Using Local authentication
login: root
Password:
local: Authentication OK
Service Type is: Administrative-User
Idle timeout is set to 3600 seconds
Connected Users:
ttyp1 root
You are logged on ttyp1
The configuration environment presents this prompt: username@hostname where username is the
login and hostname is the configurable name of the system. The service type (Administrative-User
or Login-User) indicates the user‟s privileges, the session inactivity timeout, the users connected
and the virtual tty used.
You can modify the timeout session by using:
idle <seconds>
where 0 means infinite.
This list can be checked any time through who command
:
root@Imola> who
Connected Users:
ttyp1 root
ttyp2 root
You are logged on ttyp2
root@Imola>
- Even though several users can be connected to the router, it is advisable that only one user modifies the configuration in
order to avoid undesirable effects.
