Frame Relay interface
USER GUIDE
80
DISPLAYING FRAME RELAY CONFIGURATION, STATUS AND STATISTICS
It is possible to display information about configuration, PVCs, statistics and status of the FRAME
RELAY interface by using the CLI command:
show interface frame-relay config|pvc|statistics|status
For example, the command
show interface frame-relay config
produces the following output:
root@Imola> show interface frame-relay config
hdlc0:
clock ext
protocol fr lmi ansi t391 10 t392 15 n391 6 n392 3 n393 4
The command
show interface frame-relay pvc
produces the following output:
root@Imola> show interface frame-relay pvc
Configuration for PVC pvc0:
Local IP Address: 1.1.1.1
Nexthop IP Address: 1.1.1.2
Default Route on here: yes
Masquerade: no
DLCI 16 [pvc0] Status: active,Last time pvc status changed: 0:47:11
15: pvc0: <POINTOPOINT,UP> mtu 1500 qdisc noqueue
link/dlci 00:10 peer 04:01
RX: bytes packets errors dropped overrun mcast
0 0 0 0 0 0
TX: bytes packets errors dropped carrier collsns
0 0 0 0 0 0
inet 1.1.1.1 peer 1.1.1.2/30 scope global pvc0
pvc1 is not defined
pvc2 is not defined
Configuration for PVC pvc3:
Local IP Address: 11.11.11.1
Nexthop IP Address: 11.11.11.2
Default Route on here: no
Masquerade: yes
DLCI 17 [pvc3] Status: active,Last time pvc status changed: 0:40:10
35: pvc3: <POINTOPOINT,UP> mtu 1500 qdisc noqueue
link/dlci 00:11 peer 04:01
RX: bytes packets errors dropped overrun mcast
0 0 0 0 0 0
TX: bytes packets errors dropped carrier collsns
0 0 0 0 0 0
inet 11.11.11.1 peer 11.11.11.2/30 scope global pvc3
The command
