Tiesse Imola LX 5200 User Manual

Mobile interface
USER GUIDE
91
root@Imola> show log
Dec 2 07:17:11 MR-Coach287-8 root: GPRS - Power On Modem..
Dec 2 07:17:21 MR-Coach287-8 GPRS[22884]: Trying Port /dev/ttyUSB0
Dec 2 07:17:22 MR-Coach287-8 GPRS[22884]: Modem OK
Dec 2 07:17:31 MR-Coach287-8 root: GPRS - Trying Auto Network
Dec 2 07:17:31 MR-Coach287-8 root: GPRS - Verify Network Registration
Dec 2 07:17:32 MR-Coach287-8 root: AT+CREG?
Dec 2 07:17:32 MR-Coach287-8 root: +CREG: 0,1
Dec 2 07:17:32 MR-Coach287-8 root: OK
Dec 2 07:17:32 MR-Coach287-8 root: AT+CSQ
Dec 2 07:17:32 MR-Coach287-8 root: +CSQ: 6,0
Dec 2 07:17:32 MR-Coach287-8 root: OK
Dec 2 07:17:32 MR-Coach287-8 root: GPRS - Network Registered
Dec 2 07:17:33 MR-Coach287-8 pppd[23130]: pppd 2.4.2 started by Tiesse
Dec 2 07:17:34 MR-Coach287-8 chat[23132]: send (AT+CGDCONT=1,"IP","ibox.tim.it”
Dec 2 07:17:34 MR-Coach287-8 chat[23132]: AT+CGDCONT=1,"IP","intrainwifi.tim.it
Dec 2 07:17:34 MR-Coach287-8 chat[23132]: send (AT+CGATT=1^M)
Dec 2 07:17:34 MR-Coach287-8 chat[23132]: send (ATD*99***1#^M)
Dec 2 07:17:34 MR-Coach287-8 chat[23132]: CONNECT
… … … … …
sent [LCP ConfReq id=0x1 <mru 1476> <asyncmap 0x0> <magic 0xe2270bc4>..
rcvd [LCP ConfReq id=0x0 <asyncmap 0x0> <auth chap MD5> <magic 0x6d503910>..
sent [LCP ConfAck id=0x0 <asyncmap 0x0> <auth chap MD5> <magic 0x6d503910>..
rcvd [LCP ConfAck id=0x1 <mru 1476> <asyncmap 0x0> <magic 0xe2270bc4> <pcomp>..
sent [LCP EchoReq id=0x0 magic=0xe2270bc4]
rcvd [LCP DiscReq id=0x1 magic=0x6d503910]
rcvd [CHAP Challenge id=0x1 <e4c6aed962128461f211d325443a3f44>, name = “..”
sent [CHAP Response id=0x1 <9fabe2d692114fc609f6d85634254c16>, name = "..”
rcvd [LCP EchoRep id=0x0 magic=0x6d503910 61 f2 11 d3]
rcvd [CHAP Success id=0x1 ""]
CHAP authentication succeeded
sent [IPCP ConfReq id=0x4 <compress VJ 0f 01> <addr 0.0.0.0>]
rcvd [IPCP ConfReq id=0x0]
sent [IPCP ConfNak id=0x0 <addr 0.0.0.0>]
rcvd [IPCP ConfRej id=0x4 <compress VJ 0f 01>]
sent [IPCP ConfReq id=0x5 <addr 0.0.0.0>]
rcvd [IPCP ConfReq id=0x1]
sent [IPCP ConfAck id=0x1]
rcvd [IPCP ConfNak id=0x5 <addr 172.22.1.33>]
sent [IPCP ConfReq id=0x6 <addr 172.22.1.33>]
rcvd [IPCP ConfAck id=0x6 <addr 172.22.1.33>]
Could not determine remote IP address: defaulting to 10.64.64.64
local IP address 217.1.1.1
remote IP address 10.64.64.64
GPRS LEDS MEANING
The status of the GPRS interface is indicated by 2 green LEDs named Link and Data.
LED type
LED
COLOR
BEHAVIOUR
DESCRIPTION
GPRS interface
(modem GPRS or EDGE
- models 1xx0 e 2xx0)
Link
Green
Blinking fast
Shows the sync phase with the central
Blinking slowly
1-2 seconds on: the connection has
been correctly established
