Tiesse Imola LX 5200 User Manual

Ethernet interface
USER GUIDE
45
DETECT-LINK-STATE COMMAND
You have to remember that, on some models, once configured, the Ethernet interface is always
available regardless of its operative status: the router always responds to possible requests arriving
on the IP address associated with the interface. In order to forbid these kinds of requests the
command is:
detect-link-state <interface-name>
3
The command applies to the eth0 interface for Imola LX models and to eth1 for all the others.
You don‟t need to use detect-link-state if you have a Lan Splitted configuration.
The command apply on eth0 for router Imola LX and on eth1 for the others routers. It is not
necessary to use in case of a Lan Splitted (see the specific chapter).
DISPLAYING INTERFACE STATUS
In order to display the configuration of an interface, the following CLI command is used:
ifconfig eth0
which shows:
 IP address
 Netmask
 Broadcast
 MAC address
 Static meters
In order to display the ARP table the command is:
show arp
In order to display IPv6 neighbour discovery protocol the command is:
show ipv6 neighbor
The command:
show ip interface brief
shows briefly the informations of all the network interfaces present.
root@IMOLA> show ip interface brief
show interface brief
Interface Status Protocol IP Address(s)/Description
--------- ------ -------- -------------------------
bri0 up down ISDN Channel 0 Status
bri1 up down ISDN Channel 1 Status
dummy0 down down Loopback Interface
eth0 up up 10.10.7.97/16
eth1 up up 172.151.113.1/16
eth1.10 up up 172.16.10.1/24
3
-
In order to execute the command during the reboot of the router it is necessary to set the command set autocmd detect-link-state <ifname>
