DLSW protocol
USER GUIDE
306
set dlsw sdlc-binder addr <address> sap <value> remote-sap <value>
 the xid:
set dlsw sdlc-binder addr <address> xid <value> type <value>
 and the virtual MAC address:
set dlsw sdlc-binder addr <address> vmac <mac address>
The MAC address must be introduced as a sequence of 6 bytes separated by colons,
hh:kk:xx:yy:ww:00, by using hexadecimal notation. Note that the low byte must be 00. The
associated MAC address is created from the virtual MAC address on which the address of the
station is overlaid in the low byte.
In order to remove the binder, the following command is used:
set dlsw no-sdlc-binder addr <address>
In order to check the binder log the following commands are used:
set dlsw sdlc-binder addr <address> log on
set dlsw sdlc-binder addr <address> log level <value>
set dlsw sdlc-binder addr <address> log off
DISPLAYING DSLW CONFIGURATION, STATUS AND STATISTICS
It is possible to display the DSLW configuration from the current router configuration by using the
command:
show config current
root@Imola > show config current
set dlsw local-peer ipaddr 172.151.113.1
set dlsw remote-peer ipaddr 172.151.1.1
set dlsw local-peer keepalive 0
set dlsw local-peer pacing-window 20
set dlsw remote-peer target-mac 00:c0:26:dc:d8:39
set dlsw log level 1
set dlsw sdlc-binder addr c1
set dlsw sdlc-binder addr c1 sap 8 remote-sap 4
set dlsw sdlc-binder addr c1 xid 05d15a01 type 2
set dlsw sdlc-binder addr c1 vmac 00:c0:26:a1:46:00
set dlsw sdlc-binder addr c1 log level 6
set sdlc interface hdlc0
set sdlc cu addr c1
set sdlc log level 1
set dlsw on
set wan protocol hdlc
set wan mode v28
set cdn ipaddr 1.1.1.1
set cdn encoding nrz
In order to display the status of the local peer and its connections, the following command is used:
show dlsw peers
root@Imola > show dlsw peers
