Tiesse Imola LX 5200 User Manual

Introduction
USER GUIDE
15
 2 G.SHDSL ports that can be used in 2-Wire o 4-Wire mode
 2 RS232 DCE ports with DB9F connector and/or DB25F (optional)
 2 SFP optic port (optional)
 4 ISDN BRI VoIP ports (optional)
 4 FXS VoIP and 1 FXO port (optional)
In order to distinguish the different characteristics and communication interfaces, each model is
identified by the name Imola XYZK, where:
 X identifies the type of WAN connection on mobile network
 Y identifies the type of local network connection
 Z identifies the type of WAN connection
 K identifies the type of LAN port (FE or GBE)
The values are as follows:
X
0
No mobile network connection
1
GPRS (models no longer in production)
2
GPRS / EDGE
3
GPRS / EDGE / UMTS / HSDPA
4
GPRS / EDGE / UMTS / HSDPA / HSUPA
5
GPRS / EDGE / UMTS / HSDPA / HSUPA / LTE
Y
0
1 Ethernet port present
1
2 Ethernet ports
2
5 switch Ethernet ports (4 ports in LX version)
3
1 Wi-Fi (besides Ethernet switch)
8
8 Ethernet ports
1
Z
0
No WAN connection
1
ADSL
2
ADSL2+
3
HDSL
4
SHDSL
6
VDSL2
K
0
Ethernet ports FE 10/100 Mbps
2
Ethernet ports GBE 10/100/1000 Mbps
Additional expansion cards can be mounted to provide:
 asynchronous RS232 serial connectivity through two DB9 ports or a DB9 and a DB25 port,
both for connecting serial devices such as RTU, CBT, SCADA and various controllers (IKR)
 direct connectivity on Fiber Optic via two SFP ports
1
- In the model with 8 Ethernet ports, the 6, 7 and 8 are always FE independently of the other 5, which may be the FE or GBE

Tiesse Imola LX 5200 Specifications

General

Brand	Tiesse
Model	Imola LX 5200
Category	Network Router
Language	English
