25. ROUTE SURVEYING
8. Check the EP.
Check the coordinate for the EP, and press [OK].
9. Quit inputting the IPs.
Press [OK] in the screen shown in step 8.
The screen returns to <Curve Element Setting>.
25.8.2 Inputting Curve Elements
• Automatic setting of the BP (step 3): You can set the BP for the next curve as the IP or the EP for the previous
curve (KA-2 or the EC point) in advance.
• If multiple curves overlap when the next curve is calculated based on the input curve elements (when [OK]
is pressed), the screen below is displayed.
• If the element starting point is located before the BP, the distance between those two points is displayed with
minus (-).
• If the element ending point exceeds the EP, the distance between those two points is displayed with plus (+).
Pressing [YES] continues the calculation, ignoring the overlap of the curves.
Pressing [NO] stops the calculation and return to the Input Element screen.
1. Input the IPs.
25.8.1 Inputting IPs (Intersection Points)
2. Enter the Input Element screen.
Select "Input element".
N p :
E p :
E P
4 0 0 . 0 0 0
<Curve numb e r: 2>
2 0 0 . 0 0 0
OK
1 m m
C u r v e o v e r l a p
C o n t i n u e ?
Ele men t 2 El e ment3
YES NO
Inp ut IP
Inp ut elem ent
Rev iew e lemen t
Clea r
Defin e eleme nts
To Next Page
