5. BASIC OPERATION
Softkey operation
Softkeys are displayed on the bottom line of the screen.
Inputting letters/figures
Example: Entering "JOB M" in the JOB name field
1. Press {SHIFT} to enter the alphabet input mode
Alphabet input mode is indicated by an "A" on the right of the screen.
2. Press {4}.
"J" is displayed.
3. Press {5} three times.
"O" is displayed.
4. Press {7} twice.
"B" is displayed.
5. Press {} twice.
Input a blank space.
6. Press {5} once.
"M" is displayed. Press {ENT} to complete inputting.
{F1} to {F4}
Select the function matching the softkeys
{FUNC}
Toggle between OBS mode screen pages (when more than 4 softkeys
are allocated)
{SHIFT}
Switch between numeric and alphabetic characters.
{0} to {9}
During numeric input, input number of the key.
During alphabetic input, input the characters displayed above the key in
the order they are listed.
{.}/{±}
Input a decimal point/plus or minus sign during numeric input.
During alphabetic input, input the characters displayed above the key in
the order they are listed.
{ }/{ }
Move the cursor left/right
{B.S.}
Deletes a character on the left.
{ESC}
Cancels the input data
{ENT}
Selects/accepts input word/value
JOB details
JOB name
JOB M
SCALE: 1.00000000
A
OK
