Topcon GM-100 Series User Manual

66
16. SETTING-OUT LINE
4. Enter the first point data and press [OK].
• When [LOAD] is pressed, registered coordinates can be
recalled and used.
"13.1 Entering Instrument Station Data and Azimuth
Angle PROCEDURE Reading in Registered
Coordinate Data"
5. Enter the second point data.
6. Press {FUNC}.
[OBS] is displayed.
• When not observing the first point and the second point, go
to step 11.
7. Press [OBS] on the screen of step 6 to move to observation
of the first point.
8. Sight the first point and press [MEAS].
The measurement results are displayed on the screen.
• Press [STOP] to stop the measurement.
• You can input target height here.
• The tilt screen is displayed if the instrument is out of level.
Level the instrument.
"7.2 Levelling"
9. Press [YES] to use the measurement results of the first
point.
• Press [NO] to observe the first point again.
10.Sight the second point and press [MEAS].
11. Press [YES] to use the measurement results of the second
point.
The distance between the two measured points, the distance
calculated from inputting the coordinates of two points and
the scale factors are displayed.
D e f i n e 2 n d P T
N p :
E p :
Z p :
1 1 . 7 7 5
1 1 2 . 7 0 6
1 0 4 . 0 6 9
P1
RECLOAD MEAS OK

M e a s u r e 1 s t P T
1 2 . 1 2 2
1 1 3 . 4 6 4
9 1 . 0 8 8

N p :
E p :
Z p :
MEAS
Measure 1st PT
NO
YES
HR 1.400m
SD
ZA
HA-R
A z m t h
H c a l c
H m e a s
S c a l e X
Sy=1
Sy=Sx
OK
1.0 000 91
13. 003 m
17. 294 m
S c a l e Y
1.0 000 91
93 20 3 1
