Topcon HiPer VR User Manual

Loading New Firmware
5-4
P/N: 1023998-01
Configuration
12. Click Next. The Information screen appears (Figure 5-3).
Figure 5-3: Select Device/Device Information Screens
13. Click Next. The Select Files screen appears (Figure 5-4).
14. Click the button and browse for the receiver’s *.tfi file.
15. Click Next. The Installation screen appears and the firmware begins uploading (Figure 5-4).
Figure 5-4: Select Files/Installation Screens
16. When the progress bar is filled with green, click OK in the dialog box. TRU automatically
disconnects from the receiver.
17. The Receiver will reboot a few times during firmware update.

Topcon HiPer VR Specifications

General

Battery Life	Up to 10 hours
Ingress Protection	IP67
Internal Memory	8 GB
Signal Tracking	GPS, GLONASS, Galileo, BeiDou, QZSS, SBAS
Static Accuracy Horizontal	3 mm + 0.1 ppm
Static Accuracy Vertical	5 mm + 0.5 ppm
Communication	Bluetooth, Wi-Fi
Operating Temperature	-40°C to +65°C
Update Rate	20 Hz
