E6582062
4. [Basic operation] Operation methods of motor 4-6
4
9
2) Direct access
A 4-digit communication number is input to specify
a parameter, and its setting screen is displayed
directly.
On this setting screen, you can check or change
the setting value of the parameter.
When you select "2. Direct access" on the [Setting
mode] screen and press the [OK] button, the direct
access screen is displayed.
A 4-digit communication number is displayed.
The selected digit is highlighted.
On the lower side of the screen, the title, name,
and setting value of the parameter corresponding to the communication number are displayed.
Input the communication number in the following procedure.
1 Set the digit.
When you press the [F2] key , the highlighted
character is shifted to the left. When you press the
[F3] key , the highlighted character is shifted to
the right.
Memo
• The following parameters are not displayed in the history function.
<FC: Panel run frequency>
<AUF: Guidance function>
<AUA: Application easy setting>
<AUL: Multi-rating select>
<AU1: Automatic Acc/Dec>
<AU2: Torque boost macro>
<SEt: Region setting check>
<tyP: Default setting>
<F699: Trip for test>
<F700: Parameter reading&writing access lockout>
<F737: Panel keys lockout>
<F738: Password setting>
<F739: Password verification>
<F899: Communication option reset>
Top View
Monitor
0.0HzSTOP
14:02
Direct access
0 1 0 0
Set the communication number
F100: Low-speed signal freq
0.0Hz
Top View
Monitor
0.0HzSTOP
14:02
Direct access
0 1 0 0
Set the communication number
F100: Low-speed signal freq
0.0Hz
