Toshiba TOSVERT VF-AS3 User Manual

E6582062
4-19 4. [Basic operation] Operation methods of motor
3
4
9
■ With parameters for which a value should be set
For an example, here is a procedure to set the basic parameter <ACC: Acceleration time 1>.
At that time, the current setting value, unit, setting lower limit (Min:), and setting upper limit (Max:)
are displayed.
1 Change the value with the touch wheel.
When you touch the touch wheel, the value is
highlighted, and you can change setting. When
highlighted, the setting value is being changed.
With the [F1] to [F4] keys, the following digits are
changed.
2 Press the [OK] key.
The setting value is changed, and the screen
display returns to the previous one.
Key Display Meaning
Digit to be changed in this
example
F1 x 1000
Change the digit that is the minimum digit x
1000
100 sec
F2 x 100
Change the digit that is the minimum digit x
100
10 sec
F3 x 10 Change the digit that is the minimum digit x 10 1 sec
F4 x 1
Change the minimum digit of the value
displayed
0.1 sec
Memo
• For details of the function and adjustment range of <ACC: Acceleration time 1>, refer to [5. 2.
4].
0.0HzSTOP
15:12
ACC :Acceleration time 1
Min: 0.0 Max: 6000.0
X1000 X100 X1
s
25.0
X10
CMOd : Run command select
FMOd : Frequency command select 1
dEC : Deceleration time 1
UL : Upper limit frequency
Top
0.0HzSTOP
15:12
0
1
10.0s
Easy Mode
60.0Hz
Monitor
ACC : Acceleration time 1 25.0s

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
