■ Setting list of <F710: Standard mode display> and <F720: Standard mode
display of extension panel>
Set-
ting
value
Function name Display unit
Set-
ting
value
Function name
Display
unit
0 Output frequency 0.1 Hz 71
Motor speed (estimated
value)
1
1 Frequency command value 0.1 Hz 72
Communication option
Receiving counter
1
2 Output current
1%/<F701>
setting
73
Communication option
Abnormal counter
1
3 Input voltage (DC detection)
1%/<F701>
setting
76
Terminal S4/S5 pulse train
input value
0.10%
4 Output voltage
1%/<F701>
setting
77 My function COUNT1 1
5 Stator frequency 0.1 Hz 78 My function COUNT2 1
6
Speed feedback frequency
(real time)
0.1 Hz 79
Dancer control PID result
frequency
0.1 Hz
7
Speed feedback frequency
(1-second filter)
0.1 Hz 80
Embedded Ethernet
Transmission counter
1
8 Torque 1% 81
Embedded Ethernet
Receiving counter
1
9 Torque command 1% 82
Embedded Ethernet
Abnormal counter
1
10
Output frequency during run.
Frequency command value
during stop.
Hz/free unit 83 Connected option number 1
11 Torque current 1% 84 My function COUNT3 1
12 Exciting current 1% 85 My function COUNT4 1
13 PID feedback value 0.1 Hz 86 My function COUNT5 1
14
Motor overload factor (OL2
data)
1% 90 Cumulative power ON time 100 hours
15
Inverter overload factor (OL1
data)
1% 91
Cumulative cooling fan run
time
100 hours
16
Braking resistor overload
factor (OLr data)
1% 92 Cumulative run time 100 hours
17
Braking resistor load factor
(%ED)
1% 93 Cumulative overcurrent time 100 hours
18 Input power 0.1 kW 95 Pump 0 run time 100 hours
19 Output power 0.1 kW 96 Pump 1 run time 100 hours
20 Input cumulative power
<F749> set-
ting
97 Pump 2 run time 100 hours
21 Output cumulative power
<F749> set-
ting
98 Pump 3 run time 100 hours
