5. [Fundamental operation] How to use parameters 5-72
4
5
9
22 - - 99 Pump 4 run time 100 hours
23 - - 100 Number of starting
10000
times
24 Terminal RR input value 1% 101 Number of Fwd starting
10000
times
25 Terminal RX input value 1% 102 Number of Rev starting
10000
times
26 Terminal II input value 1% 103 External equipment counter Time
27 Motor speed command - 105 Pump 5 run time 100 hours
28 Terminal FM output value 1 106 Pump 6 run time 100 hours
29 Terminal AM output value 1 107 Pump 7 run time 100 hours
30 - - 108 Pump 8 run time 100 hours
31 Communication data output
*1
109 Pump 9 run time 100 hours
32 Slot A option CPU version - 110 Number of trip Time
33 Slot B option CPU version - 111 Number of serious failure trip 1
34 Motor load factor % 112 Number of slight failure trip 1
35 Inverter load factor % 113 Number of specified trip 1 1
36 Inverter rated current A 114 Number of specified trip 2 1
37
Inverter rated current (with
carrier frequency correction )
A 115 Number of specified trip 3 1
38 Actual carrier frequency kHz 120 Internal temperature 1 °C
39 Slot C option CPU version - 124
Power circuit board
temperature
°C
40
Embedded Ethernet CPU
version
- 130 External PID3 set value 0.1 Hz
41
Terminal FP pulse train out-
put value
pps 131
External PID3 feedback
value
0.1 Hz
43
Terminal FM/AM gain setting
value
- 132 External PID3 result value 0.1 Hz
44 Terminal AI4 input value 1% 133 External PID4 set value 0.1 Hz
45 Terminal AI5 input value 1% 134
External PID4 feedback
value
0.1 Hz
46 My function monitor output 1 - 135 External PID4 result value 0.1 Hz
47 My function monitor output 2 - 150 Signed output frequency 0.1 Hz
48 My function monitor output 3 - 151
Signed frequency command
value
0.1 Hz
49 My function monitor output 4 - 152 Signed stator frequency 0.1 Hz
62 PID result frequency 0.1 Hz 153
Signed speed feedback
frequency (real time)
0.1 Hz
Set-
ting
value
Function name Display unit
Set-
ting
value
Function name
Display
unit
