E6582062
6-27 6. [Advanced] How to use parameters
3
4
6
9
6. 6. 4 Input the frequency commands by pulse trains
<F146: Terminal S4 input select>
<F147: Terminal S5 input select>
<F234: Pulse train input point 1 input value>
<F235: Pulse train input point 1 frequency>
<F236: Pulse train input point 2 input value>
<F237: Pulse train input point 2 frequency>
<F376: PG phases number select>
<F378: Pulse train input pulses number>
<F679: Pulse train input filter>
■ Function
These parameters set the frequency command characteristics by pulse train input.
You can use the terminals [S4] and [S5].
When you want to use pulse train input, set <FMOd: Frequency command select 1> (or <F207:
Frequency command select 2>) to "16: Pulse train".
■ Parameter setting
Title Parameter name Adjustment range Unit Default setting
F146 Terminal S4 input select 0: Digital input
1: Pulse train input
2: PG input
0
F147 Terminal S5 input select 0: Digital input
1: Pulse train input
2: PG input
0
F378 Pulse train input pulses
number
1-9999 pps 1000
F679 Pulse train input filter 1-1000 ms 1
F234 Pulse train input point 1
input value
0 - 100 % 0
F235 Pulse train input point 1
frequency
0.0 - 590.0 Hz 0.0
F236 Pulse train input point 2
input value
0 - 100 % 100
F237 Pulse train input point 2
frequency
0.0 - 590.0 Hz
50.0/60.0
*1
*1 Depending on the setup menu. For details, refer to [5. 3. 10], [11. 10].
F376 PG phases number
select
0: PTI (Command) - PTI (FB)
1: PTI (Command) - Digital option (FB)
2 - 5: -
6: Digital option (Command) - Non FB
7 - 9: -
10: PTI (Command) - PTI (FB inversion)
11: PTI (Command) - Digital option (FB
inversion)
12 - 15: -
16: Digital option (Command inversion) - Non
FB
0
0: Digital input
1: Pulse train input
2: PG input
0.0HzSTOP
12:58
F146 : S4 input select
