Toshiba TOSVERT VF-AS3 User Manual

E6582062
6. [Advanced] How to use parameters 6-86
4
4
6
9
5) Motor parameter setting method (Basic)
<F401: Slip frequency gain>
This parameter sets the compensation gain for motor slip.
Increasing the value will reduce motor slip.
Set <F417: Motor rated speed> and then make fine adjustments to <F401>.
Keep in mind that setting a higher value than necessary will cause unstable operation such as
hunting.
<F402: Automatic torque boost>
This parameter adjusts the primary resistive component of the motor.
Increasing this value will prevent torque reduction due to voltage drop during low speed.
Adjust the value according to the actual operation.
Keep in mind that setting a higher value than necessary will increase current at low speed and
may cause tripping.
If there is a motor test report, check the stator resistance value per phase.
<F402> (%) = (√3 x Rs x <F415> x 0.9) / (Vtype x 100)
where Rs is the stator resistance value per phase (Ω), Vtype is 200, 400 V (depends on voltage
class).
<F405: Motor rated capacity>
This parameter sets the motor rated capacity.
Check the motor name plate or test report while setting.
<F412: Leakage inductance>
This parameter sets the leakage inductance component of the motor.
Increasing this value will improve torque in the high-speed region.
<F415: Motor rated current>
This parameter sets the motor rated current.
Check the motor name plate or test report while setting.
<F416: Motor no load current>
This parameter sets the ratio of the motor no-load current to the rated current.
This is equivalent to the exciting inductance of the motor.
Check the no-load current value in the motor test report and divide it by the rated current value.
Set the calculated value in %.
F463 Speed control response
2
0.0 - 25.0 - 0.0
F464 Speed control
stabilization coefficient 2
0.50 - 2.50 - 1.00
F465 Speed reference filter
coefficient 2
0 - 100 - 35
F466 Speed control response
switching frequency
0.0 - FH Hz 0.0
*1 Depending on capacity. For details, refer to [11. 6].
*2 Depending on the setup menu. Refer to [5. 3. 10], [11. 10].
Title Parameter name Adjustment range Unit Default setting

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
