11. Table of parameters 11-8
1
9
11
F135 0135
Terminal R1 delay
time
0.0 - 60.0 s 0.0 N
[7. 2. 2]
F136 0136
Terminal R2 delay
time
0.0 - 60.0 s 0.0 N
F137 0137
Terminal FP
function 2
0 - 255
*5
- - 255 N
F138 0138
Terminal R1
function 2
- - 255 N
F139 0139
Terminal FP, R1
logic select
0: F130 and F137, F133
and F138
1: F130 and F137, F133
or F138
2: F130 or F137, F133
and F138
3: F130 or F137, F133
or F138
--0N
F140 0140
Terminal F
response time
1 - 1000 ms 1 N
[7. 2. 1]
F141 0141
Terminal R
response time
1 - 1000 ms 1 N
F142 0142
Terminal RES
response time
1 - 1000 ms 1 N
F143 0143
Terminal S1
response time
1 - 1000 ms 1 N
F144 0144
Terminal S2-S5
response time
1 - 1000 ms 1 N
F145 0145
Terminal DI11-DI16
response time
1 - 1000 ms 1 N
F146 0146
Terminal S4 input
select
0: Digital input.
1: Pulse train input
2: PG input
--0N
[6. 6. 4]
[7. 2. 1]
F147 0147
Terminal S5 input
select
0: Digital input.
1: Pulse train input
2: PG input
--0N
F148 0148
Terminal AI4 input
select
1: Voltage input (0-10 V)
2: Voltage input
(-10 to +10V)
3: Current input
(0-20 mA)
4: PTC input
5: PT100 (2-wire) input
6: PT100 (3-wire) input
7: PT1000 (2-wire) input
8: PT1000 (3-wire) input
9: KTY84 input
--1N
[6. 2. 4]
[6. 6. 2]
[6. 30. 19]
[7. 2. 1]
F149 0149
Terminal AI5 input
select
1: Voltage input (0-10 V)
2: Voltage input
(-10 to +10V)
3: Current input
(0-20 mA)
4: PTC input
5: PT100 (2-wire) input
6: PT100 (3-wire) input
7: PT1000 (2-wire) input
8: PT1000 (3-wire) input
9: KTY84 input
--1N
Title
Communication
No.
Parameter name Adjustment range Unit
Minimum
setting unit
(Panel/
Communication)
Default
setting
Write
during
running
*6
User
setting
Reference
