11. Table of parameters 11-66
1
9
11
178 179 SRVL During servo lock ON: During servo lock
[7. 2. 2]
180 181 IPU
For input cumulative
power
ON: Input cumulative power unit reach
182 183 SMPA Shock monitoring alarm
ON: Current / torque value reach the shock monitoring
detection condition
184 185 ENSA
Number of external
equipment starting alarm
ON: Number of starting of external equipment is <F658:
Number of external equipment starting alarm> or more
[6. 30. 21]
[7. 2. 2]
186 187 VFS1 V/f switching status 1 ON: V/f switching status 1
[7. 2. 2]
188 189 VFS2 V/f switching status 2 ON: V/f switching status 2
190 191 FAL Cooling fan fault alarm ON: Cooling fan fault
[6. 30. 11]
[7. 2. 2]
192 193 ETHE
Embedded Ethernet
communication time-out
ON: Embedded Ethernet communication time-out
[7. 2. 2]
194 195 CLD1 Calendar 1 ON: Calendar 1
196 197 CLD2 Calendar 2 ON: Calendar 2
198 199 CLD3 Calendar 3 ON: Calendar 3
200 201 CLD4 Calendar 4 ON: Calendar 4
202 203 PID2 During PID2 control ON: During PID2 control
204 205 PID3
During External PID3
control
ON: During External PID3 control
206 207 PID3L
External PID3 deviation
limit
ON: Within the setting value of <A346: PID3 deviation upper-
limit>, <A347: PID3 deviation lower-limit>
208 209 PID4
During External PID4
control
ON: During External PID4 control
210 211 PID4L
External PID4 deviation
limit
ON: Within the setting value of <A376: PID4 deviation upper-
limit>, <A377: PID4 deviation lower-limit>
212 213 PMPC Pump control ON: For pump operation
222 223 MYF1 My function output 1 ON: My function output 1
224 225 MYF2 My function output 2 ON: My function output 2
226 227 MYF3 My function output 3 ON: My function output 3
228 229 MYF4 My function output 4 ON: My function output 4
230 231 MYF5 My function output 5 ON: My function output 5
232 233 MYF6 My function output 6 ON: My function output 6
234 235 MYF7 My function output 7 ON: My function output 7
236 237 MYF8 My function output 8 ON: My function output 8
238 239 MYF9 My function output 9 ON: My function output 9
240 241 MYF10 My function output 10 ON: My function output 10
242 243 MYF11 My function output 11 ON: My function output 11
244 245 MYF12 My function output 12 ON: My function output 12
246 247 MYF13 My function output 13 ON: My function output 13
248 249 MYF14 My function output 14 ON: My function output 14
250 251 MYF15 My function output 15 ON: My function output 15
252 253 MYF16 My function output 16 ON: My function output 16 [7. 2. 2]
254 - AOFF Always OFF Always OFF
-
Function Number
Symbol Function Action Reference
Positive
logic
Negative
logic
