E6582062ï‚‚
11-65 11. Table of parameters
1
3
9
10
11
118 119 STPC
Stop positioning
completion
ON: Stop position completion
[7. 2. 2]
120 121 LLS During sleep ON: During sleep
122 123 KEB
During synchronized Acc/
Dec
ON: During synchronized acceleration/deceleration
124 125 TVS During traverse operation ON: During traverse operation
126 127 TVSD During traverse Dec ON: During traverse deceleration
128 129 LTA Parts replacement alarm
ON: Any one of cooling fan, control board capacitor, or power
circuit capacitor reaches parts replacement time
[6. 30. 17]
[7. 2. 2]
130 131 POT
Overtorque (OT) pre-
alarm
ON: Torque current is 70% of <F616: Overtorque detection
level during power running> setting value or more
OFF: Torque current is under <F616> x 70%-<F619:
Overtorque detection hysteresis>
[7. 2. 2]
132 133 FMOD
Frequency command 1/
Frequency command 2
ON: <F207: Frequency command select 2> enabled
OFF: <FMOd: Frequency command select 1> enabled
134 135 FL3 Failure signal 3 ON: During trip (except Emergency off)
136 137 FLC Hand/Auto
ON: Run command or panel run, OFF: Other than those at
left
138 139 FORCE During forced run ON: During forced run
[6. 31]
[7. 2. 2]
140 141 FIRE During fire speed run ON: During fire speed run
142 143 UTA Undertorque alarm ON: Undertorque alarm level or more
[7. 2. 2]
144 145 PIDF
PID1,2 frequency
command agreement
ON: Frequency commanded by <F389: PID1 set value select >
and <F360: PID1 feedback input select > are within ± <F374:
PID1 set value agreement detection band>
150 151 PTCA PTC input pre-alarm
ON: PTC thermal input value is 60% of <F646: PTC detection
resistance> or more
[6. 30. 19]
[7. 2. 2]
152 153 STO
During Safe Torque Off
(STO)
ON: Open between [STOA]-[STOB]-[PLC]
OFF: Short circuit between [STOA]-[STOB]-[PLC]
[7. 2. 2]
154 155 DISK
Analog input
disconnecting alarm
ON: The input value of terminal [II] is <F633: II analog input
disconnection detection level> or less
156 157 LI1 Terminal F ON/OFF ON: Terminal [F] is ON, OFF: Terminal [F] is OFF
158 159 LI2 Terminal R ON/OFF ON: Terminal [R] is ON, OFF: Terminal [R] is OFF
160 161 LTAF
Cooling fan replacement
alarm
ON: Cooling fan reaches parts replacement time
[6. 30. 17]
[7. 2. 2]
162 163 NSA Number of starting alarm
ON: Number of starting is <F648: Number of starting alarm>
or more
[6. 30. 21]
[7. 2. 2]
164 165 LLD2 Light load detection 2 ON: Light load detection (compatible with old model)
[7. 2. 2]
166 167 DACC During Acc ON: During acceleration
168 169 DDEC During Dec ON: During deceleration
170 171 DRUN
During constant speed
run
ON: During constant speed run
172 173 DDC During DC braking ON: During DC braking
174 175 HSTOP During hit and stop ON: During hit and stop
176 177 SRVLR
During run including
servo lock
ON: During run including servo lock [7. 2. 2]
Function Number
Symbol Function Action
Reference
Positive
logic
Negative
logic
