Configure Remote Pressure Sensor
The analog input resource for the remote differential pressure sensor
included with the flush mount room controller (FMS1650-F-1-1) should
be configured using the Analog Inputs option on the first page of the
System Setup menus. Enter the user menus and navigate to the
Analog Input 2 option on the Analog Inputs Setup menus and select
it to begin configuring the input for the remote pressure sensor as
follows:
• Analog Input: AI-2
• Linearization: Disabled
• Input Mode: Normal Mode
• Engineering Units: Inches of Water
• Input Range: 4-20mA
• Pressure Range: ±0.2500 “WC
After confirming the above settings, enter a neutral isolation mode
setpoint of 0.0000 “WC at the Enter No-ISO Setpoint configuration
screen. To enter setpoints for positive and negative isolation modes,
change the mode of isolation as required and repeat the above
procedure. This completes the configuration procedure for the remote
differential pressure sensor.
Configure Humidity Sensor
The analog input resource for the input for the relative humidity sensor
of the combination sensor from BAPI (p/n BA/10K-2-H200-R) should
be configured using the Analog Inputs option on the first page of the
System Setup menus. Enter the user menus and navigate to the
Analog Input 3 option on the Analog Inputs Setup menus and select
it to begin configuring the input for the relative humidity sensor as
follows:
• Analog Input: AI-3
• Linearization: Disabled
• Input Mode: Normal Mode
• Engineering Units: Percentage RH
• Input Range: 0-10V
After confirming the above settings, accept the default setpoint of zero
at the Enter AI-3 Setpoint configuration screen. If this controller were
targeting a humidity control application, then this setpoint would be
configured as required by the specific application. This completes the
procedure for configuring the settings for the relative humidity sensor.
Configure Flow Sensor
The analog input resource for the flow input from the DP transmitter
(Ashcroft part no. CX-4-MB2-10-1IWL) should be configured using the
Analog Inputs option on the first page of the System Setup menus.
Enter the user menus and navigate to the Analog Input 4 option on the
Analog Inputs Setup menus and select it to begin configuring the input
as follows:
• Analog Input: AI-4
• Flow Range Maximum: 1.00 “WC
• Flow Range Minimum: 0.00 “WC
• Display Air Changes: Yes
• Input Range: 0-10V
• Duct Area: 120 in
2
• Room Volume: 7500 ft
3
This completes the procedure for configuring the settings for the flow
input.
Configure Temperature Sensor
The analog input resource for the input for the temperature sensor
of the combination sensor from BAPI (p/n BA/10K-2-H200-R) should
be configured using the Analog Inputs option on the first page of the
System Setup menus. Enter the user menus and navigate to the
Thermistor Input 1 option on the second page of the Analog Inputs
Setup menus, and select it to begin configuring the input as follows:
