The following table itemizes the list of points available for integration in a building management system (BMS). This table contains the objects for
open N2 integration.
Object Instance Functional Description Read or Write
Analog Inputs
AI - 1 Analog Input 1 (default: Primary Room Pressure) Read-Only
AI - 17 Analog Input 2 (default: Secondary Room Pressure) Read-Only
AI - 18 Analog Input 3 (default: Relative Humidity) Read-Only
AI - 19 Analog Input 4 (default: Supply/Exhaust Flow) Read-Only
AI - 20 Thermistor Input 1 (default: Room Temperature) Read-Only
AI - 21 Thermistor Input 2 (default: spare temperature input) Read-Only
Analog Outputs
AO - 1 Analog Output 1 (default: Primary Exhaust Damper Control) Read-Only
AO - 11 Analog Output 2 (default: Supply/Exhaust Damper Control) Read-Only
AO - 12 Analog Output 3 (spare control output) Read-Only
AO - 13 Analog Output 4 (spare control output) Read-Only
Binary Inputs
BI - 3 Digital Input 1 (default: Primary Room Door Switch) Read-Only
BI - 4 Digital Input 2 (default: Secondary Room Door Switch) Read-Only
BI - 5 Digital Input 3 (spare digital input) Read-Only
BI - 6 Digital Input 4 (spare digital input) Read-Only
Binary Outputs
BO - 1 Relay Output 1 (default: Primary Alarm Relay Output) Read-Only
BO - 2 Relay Output 2 (spare relay output) Read-Only
BO - 3 Relay Output 3 (spare relay output) Read-Only
BO - 4 Relay Output 4 (spare relay output) Read-Only
Internal Float Values
ADF - 1 PID Control Loop 1 Setpoint (Primary Differential Pressure) Read/Write
ADF - 2 Primary Room Alarm Relay High Setpoint Read/Write
ADF - 3 Primary Room Alarm Relay Low Setpoint Read/Write
ADF - 4 Secondary Room Alarm Relay High Setpoint Read/Write
ADF - 5 Secondary Room Alarm Relay Low Setpoint Read/Write
ADF - 8 Primary Room Low Alarm Setpoint Read/Write
ADF - 9 Primary Room Low Warning Setpoint Read/Write
ADF - 10 Primary Room High Warning Setpoint Read/Write
ADF - 11 Primary Room High Alarm Setpoint Read/Write
ADF - 13 PID Control Loop 2 Setpoint Read/Write
ADF - 14 PID Control Loop 3 Setpoint Read/Write
ADF - 15 PID Control Loop 4 Setpoint Read/Write
ADF - 16 Air Change Rate based on Flow Input at AI-1 Read-Only
ADF - 17 Air Change Rate based on Flow Input at AI-2 Read-Only
ADF - 18 Air Change Rate based on Flow Input at AI-3 Read-Only
ADF - 19 Air Change Rate based on Flow Input at AI-4 Read-Only
ADF - 20 Alarm Relay 3 High Setpoint Read/Write
ADF - 21 Alarm Relay 3 Low Setpoint Read/Write
ADF - 22 Alarm Relay 4 High Setpoint Read/Write
ADF - 23 Alarm Relay 4 Low Setpoint Read/Write
METASYS N2 OBJECTS
FMS-1650
- 70 -
TRIATEK reserves the right to change product specifications without notice.
