OVERVIEW
FMS-1650 Overview
FMS-1650
TRIATEK reserves the right to change product specifications without notice.
- 4 -
The touch-screen user interface of the FMS-1650 room pressure
controller is designed to facilitate the initial setup and configuration,
diagnosis, and troubleshooting during the installation process. Each
menu screen is limited to four options, thereby simplifying navigation
through the menu system. Context-sensitive help (Figure 2) is
available at most menu screens and is accessed simply by touching
the menu title on that screen. To exit from any help screen, simply
touch the display anywhere on the popup. Multi-page menu screens
have navigation buttons at the bottom of each screen that allow the
user to move forward or backward, and include a convenient exit
button on the last screen (Figure 1) to quickly exit the menu system to
return to the main display.
To preserve the security of the configuration settings, up to ten (10)
multilevel passwords may be programmed to prevent unauthorized
access to the system configuration settings. To further prevent
unauthorized access, the FMS-1650 user menu system incorporates
display timeout periods based on the screen currently displayed. Menu
screens timeout after 90 seconds of inactivity, while popup screens
automatically timeout after 60 seconds. This prevents unauthorized
access to the menus should a unit be inadvertently left unattended at
one of the user menus or configuration screens.
Figure 2. Context-
sensitive help is
available at most menu
screens simply by
touching the menu title
at any screen.
Figure 1. Navigation
buttons appear at each
menu screen which
facilitates moving
through the user menu
system.
