FMS-1650
GENERAL
Specifi cations
Touch Screen User Interface
LCD Size ……………………………………………………………………………………………………………………………………………3.2” diagonal
LCD Type ……………………………………………………………………………………………………………………………………………Transmissive
Resolution ………………………………………………………………………………………………………………………………………240 x 320 portrait
Viewing Area ……………………………………………………………………………………………………………………………50.60 mm x 66.80 mm
Color Depth …………………………………………………………………………………………………………………………………18-bit or 262K colors
Backlight Color ………………………………………………………………………………………………………………………………………………White
Luminous Intensity ………………………………………………………………………………………………………………………………min 2500 cd/m2
Mechanical
FMS-1650 Internal Sensor Flush Mount Housing (Brushed Stainless Steel) Housing ……………………………………………5.6”W x 8.5”H x 1.9”D
FMS-1650 Display Module Housing ………………………………………………………………………………………………………3”W x 5”H x 0.75”D
Optional External Remote Sensor Housing …………………………………………………………………………………………………2”W x 3”H x 2.7”D
Stainless Steel Cover Plate for Flow Tube ……………………………………………………………………………………………2.7”W x 4.5”H x 0.2”D
Stainless Steel Cover Plate for Remote Sensor ………………………………………………………………………………………2.7”W x 4.5”H x 0.2”D
FMS-1650 w/ Flow Tube Cover Plate ……………………………………………………………………………………………………………approx. 3.5 lb
FMS-1650 w/ Optional External Remote Sensor ………………………………………………………………………………………………approx. 4.0 lb
FMS-1650 Mounting Options ……………………………………………………………………………………………………………………Surface, Flush
Flow Tube Cover Plate Mounting ……………………………………………………………………………………………………………………………Flush
Optional External Remote Pressure Sensor Mounting ……………………………………………………………………………………………………Flush
Environmental
Operating Temperature …………………………………………………………………………………………………………………32° to 125° F Operating
Operating Humidity ……………………………………………………………………………………………………………10% - 95% RH, Non-condensing
TRIATEK reserves the right to change product specifications without notice.
Part Number Guide FMS1650 - - -  
Case Style Internal Sensor
1
# Remote Sensors # Optional Sensors
2
S = surface 0 = no internal sensor 0 = no remote sensors (demo) Blank = no optional sensors
F = fl ush 1 = standard internal sensor 1 = one standard remote sensor 1 = one optional remote sensor
T = thin R = optional remote display
3
2 = two standard remote sensors 2 = two optional remote sensors
3 = three standard remote sensors 3= three optional remote sensors
4 = four standard remote sensors 4 = four optional remote sensors
A = optional no-fl ow internal sensor L = legacy standard remote sensor(s)
B = custom remote sensor
N = no remote sensors
1
Internal sensor option only available on fl ush-mount model FMS1650-F-x-x
2
This digit only applies to optional sensors specifi ed in preceding digit or when ordering legacy 2-wire remote sensors
3
Optional remote display does not include internal sensor
