Maintenance

T2-C User Guide 107

4 Wipe the printhead surface.

Make a single move from one end to the other.

Warning: DO NOT MOVE THE CLOTH BACK AND FORTH!

Always wipe with a single move from one end to the other. Do not apply too much pressure.

Just gently wipe the surface of the printhead.
