3.15.4 UTL_MIRROR_CHANNEL
Ver <= 30.4.1: Default 0, Range 0…8 + 11…14 + 21…24 + 100
Ver == 30.5.0…31.0.1: Default 0, Range 0…8 + 11…14 + 21…24 + 100 + 101
Ver >= 31.1.0: Default 0, Range 0…8 + 11…14 + 21…24 + 100 + 101 + 102
In NMS ‘EbNo and Frequency Deviation’ window, you can select to display the Freq. Adjustment
(i.e. Delta frequency) of all received packets. By changing UTL_MIRROR_CHANNEL, you may
change this to display other measurement values.
Value Measurement Description Version
0 Delta Frequency Reported by DSP (DEFAULT)
1 A/D channel 1 Tx RF Level
2 A/D channel 2 Rx RF Level
3 A/D channel 3 TXCO Voltage
4 A/D channel 4 Tx Gain
5 A/D channel 5 BUC Voltage
6 A/D channel 6 LNB Voltage
7 A/D channel 7 LNB Current
8 A/D channel 8 BUC Current
11 D/A channel 1.1 TXCO Ref High
12 D/A channel 1.2 TXCO Ref Low
13 D/A channel 1.3 OCXO Ref High
14 D/A channel 1.4 OCXO Ref Low
21 D/A channel 2.1 Tx Gain
22 D/A channel 2.2 Rx VGA1
23 D/A channel 2.3 Rx VGA2
24 D/A channel 2.4 Rx Attenuator
100 Preamble Correlation factor Reported by DSP
101 Tx RF Level Average level measured by AGC >= 30.5.0
102 Average Rx Frequency
When HUB operates in 2150-Compatibility mode,
the average Rx Frequency received from RT
defined by
UTL_DEBUG_RT_ADDRESS is logged.
>= 31.1.0
103 Delta UW Position Offset from Target UW Position (HUB) >= 31.6.0
